Eos acoustic panels – shadow
Features
- A versatile acoustic panel for walls and ceilings
- Designed to reduce and control reverberated and echo noise
Specs
- NRC: 0.20–0.70 & higher
- Composition - 100% polyester fibre, containing not less than 60% recycled material
- Thickness: 6mm, 12mm and 24mm (1/4, 1/2” and 1”)
- Pattern number: EH040ESA
- Colour: Shadow
- Horizontal repeat 1800mm (70")
- Ships as semi-rigid panels measuring 1220 x 2440mm (48 x 96”) and 1200 x 2700mm (48 x 106”)
- Manufactured with water-based inks
- Lead time:
Sample orders - in stock, ready to ship
Production 4-6 weeks
Sustainablity
- meets criteria for WELL, LEED, Green Star, and BREEAM building rating systems
- Carbon neutral product
- Carbon neutral manufacturing
- >60% recycled material
- Low VOC and CDPH compliant <0.092 mg/m3
(7 days) - Zero waste manufacturing initiative
- Sustainable supply chain and anti-modern slavery
- EPD – compliant with ISO 14025 and ISO 15804
- Declare – Red List free (third party verified)
- ISO 14001 Certified Environmental Management
- Health Product Declaration
- CDPH Standard
Fire rating
- ASTM E-84-15a, Class A, FS:0 - SD:45 for 12mm (1/2”)thickness
- ISO 9705: 1993, Classification: Group 1-S
- AS ISO 9705 - 2003, Classification: Group 1
Samples
- Samples are A5, 6mm (1/4”) thickness
Further information
- Install as butt join, negative detail or corresponding trims
- A full data sheet is available on request
- Custom panel lengths, designs and acoustic products are available on request
- Not sure how much to order?
Email us with your wall dimensions and we’ll create a visual and quote - autexacoustics.co.nz
